Switch 24 Port 10/100, 2 Gigabit uplink ports, unmanaged, Metal

Interface • Fast Ethernet: 100 Mbit / s (half duplex) 200 Mbit / s (duplex) • Gigabit Ethernet: 2000 Mbit / s (duplex) Protocol • CSMA / CD Data transfer rate • Ethernet: 10 Mbit / s (duplex) 20 Mbit / s (half duplex) • Fast Ethernet: 100 Mbit / s (half duplex) 200 Mbit / s (duplex) • Gigabit Ethernet: 2000 Mbit / s (duplex) Topology • Star Network Cable • 10BASE-T: UTP Cat. 3, 4, 5 (100 m max.) EIA/TIA-568 100-ohm STP (100 meters max.) • 100BASE-TX, 1000BASE-T: UTP Cat. 5, Cat. 5e (100 m max.) EIA/TIA-568 100-ohm STP (100 meters max.) Number of Ports • 24-port 10/100 Mbit / s • 2 10/100/1000 Mbit / s Advanced Interface • Autodetect cable polarity MDI / MDI-X on each port Indicators On the device • Power (Power) • Status (Status) At the port: • Link / Activity (State / Active) • Speed ​​of 100 Mbit / s (ports 10/100 Mbit / s) • Speed ​​of 100 Mbit / s and 1000 Mbit / s (ports 10/100/1000 Mbit / s) Switching Method • Store-and-forward The switch fabric • 8.8 Gb / s MAC-address table • 8K entries per device The study of MAC-address • Automatic updating of MAC-address table Speed ​​packet filtering • 10BASE-T: 14,880 frames / sec per port (half duplex) • 100BASE-TX: 148,810 frames / sec per port (half duplex) • Gigabit Ethernet: 1488,100 frames / sec per port Speed ​​packet switching • 10BASE-T: 14,880 frames / sec per port (half duplex) • 100BASE-TX: 148,810 frames / sec per port (half duplex) • Gigabit Ethernet: 1488,100 frames / sec per port RAM Buffer • 320Kbayt on device

מפרט טכני

• מספר יציאות: 24
• מהירות: מבואות 10/100Mbit · 1Gbit SFP Ports 2 ניהול Unmanaged Rackmount כן
• הערות: 24-Port 10/100Mbps Fast Ethernet | 2-Port 10/100/1000Mbps copper Gigabit

מק"ט יצרן: DES-1026G

אחריות יבואן רשמי. המוצר חדש באריזה מקורית.
