RUCKUS MEDIUM ENCLOSURE

מפרט טכני

• Wi-Fi Standards: IEEE 802.11a/b/g/n/ac Wave 2
• Supported Channels: 2.4GHz: 1-13 5GHz: 36-64, 100-144, 149-165
• MIMO: 4x4 SU-MIMO 4x4 MU-MIMO
• Spatial Streams: 4 SU-MIMO 3 MU-MIMO
• Radio Chains and Streams: 4x4:4
• Channelization: 20, 40, 80MHz
• Security: WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i, Dynamic PSK WIPS/WIDS
• Other Wi-Fi Features: WMM, Power Save, Tx Beamforming, LDPC, STBC, 802.11r/k/v Hotspot Hotspot 2.0 Captive Portal WISPr
• Antenna Type: BeamFlex+ adaptive antennas with polarization diversity Adaptive antenna that provides up to 4,000+ unique antenna patterns
• Antenna Gain (max): Omni -Up to 3dBi Sector -Up to 8dBi
• BeamFlex+ SINR Transmit Power Gain *: Up to 6 dB
• BeamFlex+ SINR Receive Power Gain *: Up to 4 dB
• Minimum Receive Sensitivity 1: -104dBm
• Frequency Bands: ISM (2.4-2.484GHz) U-NII-1 (5.15-5.25GHz) U-NII-2A (5.25-5.35GHz) U-NII-2C (5.47-5.725GHz) U-NII-3 (5.725-5.85GHz)
• HT20: HT40
• Rate: Pout (dBm)
• MCS0 HT20: 20
• MCS7 HT20: 17
• MCS0 HT40: 22
• MCS7 HT40: 19
• MCS0 VHT20: 22
• MCS7 VHT20: 19
• MCS0 VHT40, VHT80: 22
• MCS7 VHT40, VHT80: 19
• Peak PHY Rates: 2.4GHz: 600Mbps 5GHz: 1733Mbps

מק"ט יצרן: 5905868602418

אחריות יבואן רשמי. המוצר חדש באריזה מקורית.
